Discriptions
1.10/12/14/16/18/20AWG - 2 Stranded Conductors
2.Used to connect electrically between loudspeakers and amplifiers in Audio system, in home automation system and more
3.Great for stereo systems, security systems, intercom systems and nurse call buttons
4.Flexible design for easy routing in corners and around door-frames
5.Two conductor cable w/ red stripe for matching polarity
6.Bare copper conductor ,quality wire
Model Name
For US Market (Quality one) |
|
|
|
Model |
AWG |
Conductor |
O.D/mm |
Length |
SPU1001-BC-20 |
20AWG |
20AWG (28/0.16BC+PVC)*2F |
OD2.2*2.2MM |
100m |
SPU1001-BC-18 |
18AWG |
18AWG (42/0.16BC+PVC)*2F |
OD2.5*2.5MM |
100m |
SPU1001-BC-16 |
16AWG |
16AWG (63/0.16BC+PVC)*2F |
OD3.0*3.0MM |
100m |
SPU1001-BC-14 |
14AWG |
14AWG (105/0.16BC+PVC)*2F |
OD3.5*3.5MM |
100m |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
For Europe Market (Quality one) |
|
|
Model |
AWG |
Conductor |
O.D/mm |
Length |
SPU1001-BC-0.75 |
0.75mm² |
0.75mm² speaker cable 24x0.2BC*2F |
OD2.5*2.5mm |
100m |
SPU1001-BC-1.5 |
1.5mm² |
1.5mm² speaker cable 48x0.2BC*2/++PVC OD3.0*3.0mm |
OD3.0*3.0mm |
100m |
SPU1001-BC-2.5 |
2.5mm² |
2.5mm² speaker cable 78x0.2BC*2/++PVC OD3.5*3.5mm |
D3.5*3.5mm |
100m |
SPU1001-BC-4.0 |
4.0mm² |
4.0mm² speaker cable 126x0.2BC*2/++PVC OD4.5*4.5mm |
OD4.5*4.5mm |
100m |
