| Conductor | Material | CCA/ CCS/ Bare Copper | |
| Diameter | 1.01mm ± 0.01mm | ||
| Insulation | Material | Foam PE/ Solid PE | |
| Diameter | 4.6mm ± 0.1mm | ||
| Shielded | Material | AL Foil | |
| Braiding | Material | AL/ CCA/ CU/ TC Wire | |
| Coverage | 64/ 80/ 96/ 112/ 128/ 144 * 0.12mm | ||
| Jacket | Material | PVC/ PE Jacket | |
| Diameter | 6.9mm ± 0.1mm | ||
| Application | Applicable for video field, communication system & signal controlling system; video monitor circuitry, broadcast signal control, public TV antenna, closed-circuit TV monitor system; wireless telecommunication, transmission system & unilateral control or internal wire of high-frequency machine. | ||
| Characteristics | High degree of foaming, low dielectric constant, low capacitance, even impedance, high transmission rate, low attenuation constant, fine anti-interference performance, sound damp-proof, stable structure, long service life, good compliance, short bent semi-diameter, etc. | ||
| Products Specification | 1. Characteristic impedance: 75Ω 2. Single round bare copper conductor 3. Physical foaming polyvinyl insulated 4. Aluminum shielded outside 5. Soft tinned copper wire braid shielded 6. PVC & PE jacket 7. Keeping working temperature under 70℃ for long time 8. Packaging: 100m/ 200m/ 300m/ Roll. Customised is OK. |
||
| Model Name | AWG | Conductor | Braiding | OD | Remark |
| RG6-001-CCS | 18AWG | 1C/1.02 CCS | 64/0.12AL | OD6.9mm | |
| RG6-002-CCS | 18AWG | 1C/1.02 CCS | 112/0.12AL | OD6.9mm | High density brariding |
| Remark : if you think the price is expensive ,we can lower the braiding to 32/0.12AL or 48/0.12AL | |||||
| Model Name | AWG | Conductor | Braiding | OD | Remark |
| RG6-001-BC | 18AWG | 1C/1.02 BC | 64/0.12AL | OD6.9mm | |
| RG6-002-BC | 18AWG | 1C/1.02 BC | 112/0.12AL | OD6.9mm | High density brariding |
| Remark :1.BC Conductor with good singal transmission than CCS, 2. if you think the price is expensive ,we can lower the braiding to 32/0.12AL or 48/0.12AL |
|||||
