Discriptions:
1.【4K HDMI Cable 2.0】HDMI cables support Ultra HD 4K(2160p), QHD 2K(1440P), HDCP 2.2, including Audio Return Channel(ARC), Dolby Atmos, Dolby TrueHD 7.1 audio and 3D vitural effect, enjoy full HD TV sound quality while experiencing deep colors and high-resolution images, provides you the visual experience of ultra high definition.
2.【Ultra High Speed HDMI Cable with Ethernet】This HDMI to HDMI cable transfers data to speeds of up to 18Gbps bandwidth, giving you a faster and smoother screen whether watching TV, gaming or working. The 2.0 HDMI cable transfers audio, video and photos at lightning speed without waiting for buffering. Plug and play, no pre-installed drivers required.
3.【Reliable Signal Transmission】Bare copper core wire with multiple shielding ensures efficient transmission with less data loss. Exclusive TMDS technology ensures EMI reduction, to keep stable signal transmission and minimize signal loss. Give you an immersive experience without interruption and support Mirror and Extended Mode for your different requirements.
4.【Good Durability and Flexibility】Features an ultra-durable nylon-braided jacket with a bending test of 10000+ and high quality 24K gold plated connectors, and this HDMI cables can maintain a balance of toughness and flexibility without being too stiff.
5.【Universal HDMI Cable】Compatible for all HDMI devices.Blu-ray players, PC, AV receiver, Apple TV, Roku streaming media player, PS5, PS4, Play Station, Xbox One, Ultra 4K TV(UHD TV), HDTV, laptop , Monitor, Projector and more.
Specifications
Model |
Certified high speed 4K HDMI Cable |
Version |
HDMI2.0v( Backwards compatible with earlier version) |
Conductor Material |
Bare copper |
Conductor Size |
(1-3M)30AWG/or 28AWG ,( 5M )26AWG |
OD |
30AWG(OD6.0mm) ,28AWG(OD7.3mm) 26AWG(OD8.0mm) 24AWG (OD9.0mm) |
Wire |
19+1 |
Connector type |
HDMI A Male To A Male |
Plug |
Gold plated |
UnShield/Shield |
Double shielded |
Jacket |
PVC Jacket |
Connector |
Aluminum shell |
Resolution |
4K@60Hz /1080P |
Bandwith |
18Gbps |
Resolution |
3840*2160p |
Function |
HDR,HDCP2.2,Dolby atomos |
Application |
Ultra HDTV, Projector ,set-top box ,Blue-ray,DVD, PS5/PS4 |
Package |
Giftbox ( Customied logo could be printed on the label of box) |
Compatible |
The hdmi 2.0 cable is compatible for your streaming devices ,Playstation 5(PS5),XBOX Series X,Apple TV 4K,Mackbook Pro 14/16(Apple NI Pro/Max),NVDIA SHIELD TV ,Fire TV, Roku Ultra TV ,Blue-ray players ,Microsoft XBOX 1,Nintendo Switch and other HDMI-enabled devices to your HDTV ,Monitors ,displayers or Projectors |
2.1V HDMI QR CODE Sticker Available lengths |
1m ,2m ,3m ,5m |
How to choose AWG Spec for different meters:
AWG |
Conductor |
Length |
Pass HDMI ATC Test |
Image testing (3480*2160 60hz) |
OD |
32AWG |
BC |
1-2M |
OK |
OK |
OD5.5mm |
BC |
3M |
NG |
30AWG |
BC |
1-3M |
OK |
OK |
OD6.0mm |
BC |
5M |
NG |
4K/30hz |
28AWG |
BC |
1-3M |
OK |
OK |
OD7.3mm |
BC |
5-7.5M |
NG |
OK |
BC |
10M |
NG |
1080P |
The normal HDMI Cable over 7m will have singal loss ,only support 4k30hz .This cable with active chipset (Booster) can be a good solutions to support 4k@60hz 4:4:4 .
AWG |
Conductor |
Length |
Pass HDMI ATC Test |
Image testing (3480*2160 60hz) |
OD |
No booster |
with Booster |
No booster |
with Booster |
26AWG |
BC |
5M |
OK |
|
OK |
|
OD8.0mm |
BC |
6M |
NG |
OK |
OK |
|
BC |
8M |
NG |
OK |
OK |
OK |
BC |
10M |
NG |
OK |
OK |
OK |
BC |
15M |
NG |
NG |
NG |
OK |
24AWG |
BC |
10M |
NG |
|
OK |
|
OD9.0mm |
BC |
15M |
NG |
OK |
OK |
|
BC |
20M |
NG |
NG |
NG |
OK |
BC |
25M |
NG |
NG |
NG |
4K/30hz |
BC |
30M |
NG |
NG |
NG |
1080P |
Remark: if want Pass HDMI ATC Test ,For 10m 15m ,we recommend the HDMI Cable with booster.Exceed 15m ,we recommend the HDMI AOC Cable |
